Web Extra: Slideshow: How to Make a 3-D Printed Hand

Published in Insight - November 2014
the structure of the hand before the foam is added

John Schull, founder of e-NABLE, acquaints, Johns Hopkins surgeon Albert Chi with a prosthetic device made by e-NABLE volunteers.

hand printing process in printer

Based on a patient’s measurements, a computer application generates all of the files needed to print a hand. The printing process takes about 10 to 15 hours to complete one hand.

close up of hand being printed inside of 3D printer

A 3-D printer melts plastic and then deposits layer upon layer—similar to how a hot glue gun works—of plastic to create the shape of each piece of the hand.

the structure of the hand before the foam is added

After printing the pieces, e-NABLE volunteers sand each one to ensure they are clean, smooth and ready for the next step.

shaving down foam to make adjustments to 3D printed hand

After sanding and drilling, the pieces are assembled with screws, cords, padding, Velcro and sleeves.

the structure of the hand before the foam is added

Johns Hopkins trauma surgeon Albert Chi marvels at how a completed 3-D printed hand is powered by the flex of a wrist.
